Portable Handheld Fiber Laser Cleaning Machine

Product Description

Precision Laser Cleaning Machine — Advanced Non-Contact Surface Treatment

Utilizes high-energy laser beams to remove rust, oil, paint, and oxide layers without physical contact, eliminating mechanical wear and substrate damage.

Delivers precise, selective cleaning that preserves the integrity of the base material, making it ideal for delicate components and high-value parts.

Environmentally friendly process with no chemicals, no abrasives, and minimal waste, reducing disposal costs and workplace hazards.

Compact, easy-to-operate design with adjustable power settings for a wide range of cleaning applications.

Suitable for metals, alloys, and selected non-metallic surfaces, offering a versatile solution for maintenance, restoration, and pre-treatment.

Industrial Laser Cleaning System — High-Efficiency, Cost-Effective Surface Preparation

Rapidly removes rust, grease, coatings, and contaminants from metal surfaces, dramatically reducing cleaning time compared to traditional methods.

Non-abrasive and non-contact operation extends tool life, minimizes consumable costs, and avoids secondary waste streams.

Safe, efficient, and portable, enabling consistent, repeatable results for high-volume production lines and complex geometries.

Low energy consumption and minimal maintenance requirements lower total operating costs over the equipment's lifespan.

Robust industrial construction ensures reliable performance in demanding environments such as automotive, aerospace, mold maintenance, and heavy equipment repair.

Product Description

Parameter	Specification
Product Name	Smart Handheld Cleaning Head
Fiber Interface	QBH
Wavelength Range	1070 ± 20 nm
Rated Power	6 kW
Collimating Focal Length	75 mm
Focusing Focal Length	1500 mm
Scan Width	200–500 mm
Scan Speed	40,000 mm/s
Auxiliary Air Pressure	0.5–0.8 MPa
Effective Clear Aperture	Φ20
Weight	2.2 kg

Parameter	Specification
Product Name	6000W Laser Source
Operation Mode	Continuous / Modulated
Rated Output Power	6000 W
Power Adjustment Range	10%–100%
Central Wavelength	1075–1085 nm (Standard: 1080 nm)
3dB Spectral Width	4–6 nm
Long-Term Power Instability	≤ ±1.5%
Modulation Frequency	≤ 5000 Hz
Duty Cycle Range	1%–100% (Pulse Width ≥ 160 μs)
Red Laser Power	1–3 mW
Output Fiber Core Diameter	50–75 μm
Beam Quality (BPP)	2.7–3.1 mm·mrad
Output Fiber NA	0.2–1
Output Cable Length	20 m
Operating Voltage	3-Phase 380 VAC ±15%, 50/60 Hz
Control Interface	AD / RS-232 / Ethernet
Power Consumption	16 kW
Water Flow Requirement	≥ 60 L/min
Water Temperature Requirement	21–22 °C
Operating Ambient Temperature	10–40 °C
Operating Ambient Humidity	30%–90%
Storage Temperature	-10–60 °C
Dimensions	455 × 802 × 168 mm
Weight	70 kg
