Closed type fiber laser cutting machine

BW-G6025 Closed type fiber laser cutting machine

Output Power: 3000W/6000W/12000W/15000W (Optional)
Model: BW-G6025
Table Size: 3m*1.5m/4m*2m/6m*2m/6m*2.5m etc (Optional)
Share
BW-G6025 Closed type fiber laser cutting machine
BW-G6025 Closed type fiber laser cutting machine
BW-G6025 Closed type fiber laser cutting machine
BW-G6025 Closed type fiber laser cutting machine
BW-G6025 Closed type fiber laser cutting machine
BW-G6025 Closed type fiber laser cutting machine
Product Description
Product description
BW-G6025 Series fiber laser cutting machine use advanced structure design and excellent machine tool performance. We adopt world-class CNC control system and fiber laser source. We adopt gantry double drive structure and the base and the rack are integrally welded, and after vibration aging treatment, the stress during welding is eliminated, and the rough machining is followed by machining; the pinion gear transmission structure has fast speed and high precision, and can be formed in one cutting without subsequent processing.
With high cutting efficiency,best layout cutting design, our machine can help you save raw materials. We use advanced technology can speed up the progress of your company's new product development and recover your equipment investment costs in short time.
Our machine is widely used in sheet metal processing, billboard production, mechanical parts, kitchen utensils, metal crafts, saw blades, hardware and other industries;It can be used to cut carbon steel, stainless steel, aluminum, copper, brass and other metals.
Product description
Design concept
Baiwei 12000w fiber laser cutting machine is developed and manufactured according to market demand.
Design concept: simple, practical and intelligent.
We adopt gantry double-drive structure design, and the bed is welded as a whole. After heat treatment and vibration aging, large-scale gantry milling is used for roughing and finishing, and the mounting surface of guide rail and rack is formed at one time.
We adopt world-class intelligent numerical control system, high-performance servo drive + motor, high-precision reducer + rack and pinion + guide rail drive.
Design concept
Compatible material
Baiwei 12000w high-power laser cutting machine can cut various thick plates, such as carbon steel plates, stainless steel plates, aluminum plates and other metal. Most importantly, we can ensure no deformation during cutting process.
We use  parallel exchange platform, the work piece exchange can be completed within 20 seconds, which greatly improves the processing and cutting efficiency
Smooth cutting surface without burrs
High precision, fast speed, narrow slit, and minimum heat-affected zone. The laser cutting material will not scratch the work piece, and the work piece has no mechanical deformation.
Compatible material
Core functions
1. Intelligent processing reduces labor intensity and improves processing efficiency.
2. Zero-second piercing improves the integrity of the work piece and ensures the best cutting section.
3. Precise cutting and it can reach the maximum cutting thickness of this machine;
4. Perfect sharp-angle cutting technology to improve high-quality cutting.
5. Double exchange table, which can save loading and uploading time, save labor cost;
6. Automatic positioning and edge search functions make cutting more convenient.
Core functions
HypCut
Cypcut cnc control system is customized software developed for high-power laser cutting. A professional process is provided for high-power laser cutting, which can realize intelligent production. It supports the planning and scheduling to assist production management; its modular design provides users with more concise and efficient operations and assists users in quickly completing production.
HypCut
Parameter
Models BW-G3015 BW-G4015 BW-G4020 BW-G6020 BW-G6025 Optional
Cutting range 3000x1500mm 4000x1500mm 4000x2000mm 6000x2000mm 6000x2500mm Optional
Laser power 3kw/6kw/12kw/15kw/20kw/30kw
Max moving speed 120m/min
Max cutting speed 35-80m/min
Positioning  accuracy ±0.03mm
Repositioning  accuracy ±0.02mm
Min line width 0.1mm
Industry Applications
Main structural components
Laser Source
Laser Source
Laser Cutting Head
Laser Cutting Head
High Precision Gear and Rack
High Precision Gear and Rack
Japan Shimpo Reduce
Japan Shimpo Reduce
Hanli Water Chiller
Hanli Water Chiller
Japan Panasonic Servo Motor
Japan Panasonic Servo Motor
