Open type fiber laser cutting machine

BW-G3015 3kw open type fiber laser cutting machine

Baiwei BW-G3015 fiber laser cutting machine as one classic model,widely used in manufacturing, such as sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway parts automobiles, engineering machinery, precision parts, ships, metallurgical equipment, elevators metal processing,and other manufacturing and processing industries.
Output Power: 3kw/4kw/6kw/8kw/12kw (Optional)
Model: BW-G3015/BW-G4015/BW-G6015 (Optional)
Table Size: 3m*1.5m/4m*1.5m/6m*1.5m (Optional)
Share
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Open type fiber laser cutting machine
Product Description
Industry Applications
Baiwei BW-G3015 fiber laser cutting machine as one classic model,widely used in manufacturing, such as sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway parts automobiles, engineering machinery, precision parts, ships, metallurgical equipment, elevators metal processing,and other manufacturing and processing industries.Used for cutting a variety of metal plates, mainly used in stainless steel, carbon steel, galvanized sheet, electrolytic plate, brass aluminum, various alloy plate, rare metal and other metal materials.
Industry Applications
High precision machine bed
1. Fiber laser cutting machine lathe bed part completely independent research and development, by the party welding lathe bed base, through the large gantry milling machine.
2. For large machine bed we have many vears of experience in processina. each machine bed will be placed 30 to 45 days after rough machining natural failure, the internal stress release completely again after finishing, ensure the machining accuracy. High strength, stability, ensuring 10 years of use without distortion.
High precision machine bed
Advantage of fiber laser cutting
1. Adopting gantry dual drive structure, high precision gear, gear reducer drive and linear guide rail drive smoothly, high speed, high accuracy.
2. The imported servo motor is Germany, America original imported servo motor (Various options ) and drive system,with higher stability, higher speed and faster acceleration speed.
3. Using the special control system of optical fiber laser, all dicital CNC servo motor communication humanized design, operation is faster.
4. The optical fiber laser cutting head and Z-axis transmission system are adopted, and the speed anc precision are higher.
5. Adopting leading technology, small volume, high beam quality.
6. The new peripheral design can enter the equipment working area from 3 different directions.
Advantage of fiber laser cutting
Fiber laser features
1. Good laser beam quality, Steel cast structure, longtime service life
2. High output stability, high performance
3. Low power consumption
4. Small size
5. Optical fiber laser cutting machine has obvious advantages in thin plate cutting
6. 100,000 hours of lifetime, free maintenance; Low energy consumption, only 20%-30% of the traditional CO2 machine.
Fiber laser features
HypCut
Cypcut 2000C system is a software specially developed for the deep customization of the laser cutting industry. It is easy to use, rich in functions, and suitable for various processing occasions. It is widely used in the field of metal laser cutting. ; Nesting. The arrangement of parts is more reasonable, reducing the waste of plates; one-key cutting; fast cutting of plates to recycle remaining materials; automatic edge detection.
HypCut
Parameter
Models BW-G3015 BW-G4015 BW-G4020 BW-G6015 BW-G6020 Optional
Cutting range 3000x1500mm 4000x1500mm 4000x2000mm 6000x1500mm 6000x2000mm Optional
Laser power 3kw/4kw/6kw/8kw/10kw/12kw/15kw/20kw/30kw
Max moving speed 100m/min
Max cutting speed 35-80m/min
Positioning  accuracy ±0.03mm
Repositioning  accuracy ±0.02mm
Min line width 0.1mm



Cutting samples
Main structural components
Laser Source
Laser Source
Laser Cutting Head
Laser Cutting Head
High Precision Gear and Rack
High Precision Gear and Rack
Japan Shimpo Reduce
Japan Shimpo Reduce
Hanli Water Chiller
Hanli Water Chiller
Japan Panasonic Servo Motor
Japan Panasonic Servo Motor
