How much of the metal laser cutting machine?

BW-G12025 Closed type metal sheet laser cutting machine machine

Fiber laser cutting machine adopts the most advanced fiber laser output laser beam of high energy density, and focused on the workpiece surface, making areas on the workpiece be melting and gasification instantly by ultra fine focal spot light;Automatic cutting is achieved by moving the light spot through the CNC mechanical system.It is one of the high-tech equipment with features of the most advanced optical fiber laser technology, numerical control technology, precision machinery technology.
Output Power: 6kw/8kw/10kw/12kw/15kw/20kw/30kw (Optional)
Model: BW-G12025
Table size: 12*2.5m
Share
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
BW-G12025 Closed type metal sheet laser cutting machine machine
Product Description
Industry Applications
Baiwei BW Series fiber laser cutting machine as one classic model,widely used in manufacturing, such as sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway parts, automobiles, engineering machinery, precision parts, ships, metallurgical equipment, elevators , metal processing,and other manufacturing and processing industries.Used for cutting a variety of metal plates, mainly used in stainless steel, carbon steel, galvanized sheet, electrolytic plate, brass, aluminum, various alloy plate, rare metal and other metal materials.
Industry Applications
High precision machine bed
1. Fiber laser cutting machine lathe bed part completely independent research and development, by the party welding lathe bed base, through the large gantry milling machine.
2. For large machine bed we have many years of experience in processing, each machine bed will be placed 30 to 45 days after rough machining natural failure, the internal stress release completely again after finishing, ensure the machining accuracy. High strength, stability, ensuring 10 years of use without distortion.
High precision machine bed
Advantage of fiber laser cutting
1. Adopting gantry dual drive structure, high precision gear, gear reducer drive and linear guide rail, drive smoothly, high speed, high accuracy.
2. The imported servo motor is Germany, America original imported servo motor (Various options ) and drive system,with higher stability, higher speed and faster acceleration speed.
3. Using the special control system of optical fiber laser, all digital CNC servo motor communication, humanized design, operation is faster.
4. The optical fiber laser cutting head and Z-axis transmission system are adopted, and the speed and precision are higher.
5. Adopting leading technology, small volume, high beam quality.
6. The new peripheral design can enter the equipment working area from 3 different directions.
Advantage of fiber laser cutting
Fiber laser features
1. Good laser beam quality, Steel cast structure, longtime service life
2. High output stability, high performance
3. Low power consumption
4. Small size
5. Optical fiber laser cutting machine has obvious advantages in thin plate cutting
6. 100,000 hours of lifetime, free maintenance; Low energy consumption, only 20%-30% of the traditional CO2 machine.
Fiber laser features
HypCut
Cypcut cnc control system is customized software developed for high-power laser cutting. A professional process is provided for high-power laser cutting, which can realize intelligent production. It supports the planning and scheduling to assist production management; its modular design provides users with more concise and efficient operations and assists users in quickly completing production.
HypCut
Parameter
Models BW-G3015 BW-G4015 BW-G4020 BW-G6020 BW-G6025 Optional
Cutting range 3000x1500mm 4000x1500mm 4000x2000mm 6000x2000mm 6000x2500mm Optional
Laser power 3kw/4kw/6kw/8kw/10kw/12kw/15kw/20kw/30kw
Max moving speed 120m/min
Max cutting speed 35-80m/min
Positioning accuracy ±0.03mm
Repositioning accuracy ±0.02mm
Min line width 0.1mm
Industry applications
Main structural components
Laser Source
Laser Source
Laser Cutting Head
Laser Cutting Head
High Precision Gear and Rack
High Precision Gear and Rack
Japan Shimpo Reduce
Japan Shimpo Reduce
Hanli Water Chiller
Hanli Water Chiller
Japan Panasonic Servo Motor
Japan Panasonic Servo Motor
